N106DS Weight & Balance
Station Mass (lb) CG (mm)
Empty Mass 520 706
Front Seat -508
Front Ballast -970
Baggage 119
Wing Baggage 221
Total - -

Flight Parameters

Loading
Parameter Value
Empty Weight 520 lb
Max. Weight 838 lb
Max. Load 309 lb
Min. Front Seat Load 121 lb
Max. Front Seat Load 243 lb
Limit Load Factor 5.3 g (-2.6 g)
Ultimate Load Factor 8.0 g (-4.0 g)

Limiting Speeds
Parameter Symbol Value
Max. Aerotow Speed VT 81 kt
Max. Winch Speed VW 70 kt
Maneuvering Speed VA 84 kt
Gusty Conditions Speed VB 84 kt
Never Exceed Speed VNE 119 kt

Performance Speeds @ 573 lb
Parameter Value
Stall 30 kt
Stall (45 deg.) 36 kt
Min. Sink (105 ft/min) 33 kt
Best Glide (35:1) 38 kt
Approach 49 kt
